How to Serve a Typed AI Endpoint with Pixeltable

Summary: A Pixeltable service turns tables into HTTP routes. You declare the table and its routes in one app.py, run two commands to serve it locally, and three to host it on Pixeltable Cloud. Every service publishes an OpenAPI schema, so a TypeScript app gets generated types for every route, and a hosted service accepts only requests that carry a Pixeltable API key. This post walks the whole path, from the table to a typed call in a Next.js app.

The reference docs are HTTP serving and Deploy to Pixeltable Cloud. Everything below uses Pixeltable 0.7.11 or later. pxt login, pxt whoami, and pxt key need 0.7.10 or later. Configuration of the hosted database is in Configure Pixeltable Cloud.

What a service gives you#

A route is a table operation exposed over HTTP. You choose the operation and the columns; Pixeltable writes the handler, the request and response models, and the schema.

Routes can accept file uploads, return a file instead of JSON (return_fileresponse=True), or run in the background and return a job handle (background=True).

Declare the table and its routes#

This is the Quickstart application. pxt service example --out app.py writes it for you.

Each column named in outputs becomes a typed field of the response, computed columns included. Swap pxt.String for pxt.Image, pxt.Video, pxt.Audio, or pxt.Document and the same routes serve a media pipeline.

Serve it locally#

pxt schema update creates the tables; it does not start HTTP. pxt service update starts HTTP; it does not create tables. Pass -f whenever a script, CI job, or coding agent runs these commands: without a terminal to confirm in, commands that change things refuse to proceed.

The service gets its own port, so read the endpoint from pxt service list --json rather than assuming port 8000. Interactive docs are at /docs and the schema at /openapi.json. A local service needs no key.

Deploy the same file to Pixeltable Cloud#

pxt new creates a free hosted database with no account and prints a claim link. A pxt login session is enough for this deployment if you already have an organization. You do not need an API key until a backend calls the hosted service. If a key is set in the environment or in the config file, it takes precedence over the login session, so remove a stale one before you sign in.

Name the hosted database in pixeltable.toml. Keep the local entry pxt init wrote. If pxt init wrote pyproject.toml, use [[tool.pixeltable.database]] instead. pxt org create provisions the first database as main, so a new organization uses pxt://yourorg:main. The examples below use pxt://acme:main; replace both parts with yours. What the entry controls, including when the image rebuilds, is in Configure Pixeltable Cloud.

Wait until pxt db status shows AVAILABLE. Until then, pxt db update is refused. Then run these commands from the project directory. Add -f when there is no terminal to confirm in:

1. pxt db update uploads the project onto the database and updates its image and size. It does not insert rows and it does not start endpoints. It rebuilds the image only when the environment changed, which is the slow step. A code change is an upload. The first update takes several minutes.
2. pxt schema update creates the tables. It does not start HTTP.
3. pxt service update starts the hosted service. pxt service run is local only.

The hosted image installs the Pixeltable version your lockfile (uv.lock or requirements.txt) pins, so pin 0.7.11 or later there too. pxt service list pxt://acme:main prints the service URL. The host looks like https://{org}-{db}.svc.pxt.run/<service>. Copy it from the command. Do not hardcode it, and do not send service traffic to the control-plane host. pxt service diff app.py pxt://acme:main shows what would change before you apply it. The docs list what to run after each kind of change.

Give your app its own key#

Your app server needs a key that does not expire and does no more than the app needs. Create one per app and environment:

With the grant, the key belongs to the organization and can call the ingest service and nothing else. It cannot list services, reconfigure them, or reach another database. Keys with grants are a preview; until your organization has them, omit --grant for a key that acts as you. The secret prints once. Store it in your app server's environment as PIXELTABLE_API_KEY, never under a NEXT_PUBLIC_ name that would ship it to the browser. See pxt key for the full grant table.

Generate TypeScript types from the schema#

A hosted schema needs the key to download. It declares the X-api-key header on every route, so generated clients know how to authenticate:

File responses are typed as binary, and the background job status route is in the schema, so polling is typed too. Regenerate the file whenever the Python routes change, and let your TypeScript check catch any mismatch before you deploy.

Call it from a Next.js server#

Generated types do not check a raw fetch, so call routes through openapi-fetch. Run npm install openapi-fetch server-only and add src/lib/pixeltable-client.ts:

The key is set once on the client, so no call has to pass it. import 'server-only' makes the build fail if a client component imports the module. Call it from a Server Action:

The same module calls a local service: point PIXELTABLE_SERVICE_URL at the local endpoint and leave PIXELTABLE_API_KEY unset. A deployment on Vercel or any other host needs the hosted endpoint, since it cannot reach your laptop. In the Cloud dashboard, the service page's API docs lets you try every route as your signed-in user, and Use this endpoint gives server-side snippets.

Handle errors and retries#

PixeltableError.body is the parsed error response. Branch on the shape of its detail, not on the status:

The gateway answers these itself, with the same object:

Retry a write only when detail.retryable is true, waiting retry_after seconds when it is present. That one rule covers service and gateway errors alike.

Files, uploads, and background jobs#

• File responses. A return_fileresponse=True route needs parseAs: 'blob', or parseAs: 'stream' to pipe the body through your Route Handler with the upstream Content-Type. Without it the client tries to parse the file as JSON.
• Uploads. Generated types describe upload fields as strings, so send uploads with fetch, a FormData body, and the same X-api-key header. Let fetch set the multipart boundary.
• Background jobs. A background=True route returns an id and a job_url right away. Polling is a typed call on the same client: pixeltable.GET('/_pxt/jobs/{job_id}', { params: { path: { job_id: id } } }) returns pending, done with the result, or error with an error_detail that follows the same retry rule.
• Media outputs. Image and video URLs in a hosted JSON response are signed and expire after an hour. Render them directly; do not store them.

Secrets, logs, and changes#

Provider keys such as OPENAI_API_KEY are secrets, not API keys. Set them in the dashboard or with the CLI. A running process keeps the values it started with, so restart what should read them: the database for work on its tables, and each service for its routes.

A database secret overrides an organization secret of the same name. After a code change, run pxt db update and then pxt service update; after a column change, add pxt schema update between them.

The checklist#

1. Pin Pixeltable 0.7.11 or later in the project's lockfile.
2. Serve locally first, with -f in anything scripted.
3. Sign in with pxt login, or export one API key; a stored key wins over the login.
4. Wait until pxt db status shows AVAILABLE, then run pxt db update, pxt schema update, and pxt service update.
5. Create one key per app and environment, granted only the service it calls.
6. Generate types from the hosted schema and regenerate after every route change.
7. Call the service from server code only, through the typed client.
8. Check from outside: a request without the key returns 401 with a JSON detail, and one with the key returns 200.
9. Retry only when detail.retryable is true.
10. Set provider secrets, then restart the database and each service.

Full reference: HTTP serving, Deploy to Pixeltable Cloud, and the CLI. The database entry, image rebuilds, secrets, and keys are in Configure Pixeltable Cloud. For why the same file runs locally and in the cloud, read why the local-cloud loop matters.
